1R1G1B Stage LED Screen SMD2121 High Brightness For Concerts/Events/Competitions

Brand Name : SCX

Model Number : P3.91

Certification : CE,ROHS,FCC,SASO

Place of Origin : China

MOQ : 1 SQM

Price : USD 600-2000

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 2000 sqm per month

Delivery Time : 7working days

Packaging Details : Flight Case , Size: 60x62x50cm, Wooden Case, Size:70x65x55cm

Module Size : 250mm x 250mm

Brightness : ≥1100 cd

Module Weight : 0.3kg

Pixel Format : 1R1G1B

Color Temperature Condition : 3500K～9500K,(can be adjustable)

Number of Colors : 16.7 trillion

Usage : dj,show,disco

Display function : Video,pictures,Animation,words,Graphics

Life span : 100000hours

Contact Now

Manufacturing Led Stage Backdrop Screen Indoor/ Outdoor P3/P3.91 Rental LED Display For Stage/Concert/Events/Competition

Features :

1. Corner protection design
This can avoid cabinet crush,and protect the leds during transportation and installation ,which reduce maintenance cost,reduce the likelihood of any service issue.

2. Maintenance difficulties are solved and it truely realizes dot-to dot mainterance.

3. Dual back-up for signal cable

4. this cabinet are avaliable for P2.97, P3.9 and P4.8 , both indoor and outdoor.

5. Power box modular design, Future maintenance is more convenient.

Product Description

Item		Specification
LED Parameters	Luminous Intensity	R:620-630, G:520-535, B:465-475
	Wavelength	R:400-500mcd, G:1800-2200mcd, B:350-450mcd
	Test Condition	R:25℃,20mA, G:25℃,20mA, B:25℃,20mA
LED Module	Led Type	SMD 3 IN 1
	Pixel Pitch	3.91 mm
	LED Shape & Size	2mm SMD 2121
	Encapsulation Type	1R1G1B
	Module Dimension	250mmx250mm
	Module Resolution	64 ×64
	Module Weight	0.20 KG
	Pixel Density	65410
	Driving Mode	1/16
	Module Power Consumption	20 W
LED Cabinet	Cabinet Size	500mm(W)x 500mm(H)/ 500mm(W)x 1000mm(H)
	Cabinet Thickness	70 mm
	Cabinet Resolution	128x128
	Cabinet Material	Die Casting Aluminum Cabinet
Screen	Use	Rent
	Cabinet Weight	6.5 KG/12kg
Optical parameters	Brightness	≥1500 cd
	Contrast Ratio	≥3000:1
	Single-point Brightness Correction	Available
	Single-point Color Correction	Available
	Surface Evenness	GAP< 1mm
	Color Temperature Condition	3500K～9500K,(can be adjustable)
	Viewing angle	140°(Horizontal),140°(Vertical)
	Gray Scale	16 bit
	Minimum Viewing Distance	3.91 m
	Brightness Adjustment	0-100% 8 levels
Power Supply	Operation Power	AC90-260V 50-60HZ
	Max Power Consumption	700 W /m²
	Average Power Consumption	350 W /m²
Control System	Control Mode	Synchronous Control by Linsn system
	Frame Update Frequency	≥600Hz
	Screen Refresh Frequency	≥38400Hz
	Gamma Correction	(-0.5—5.0)
	Input Signal Support	Composite,S-Video,Component, VGA,DVI,HDMI,SDI,HD_SDI
	Control Distance	UTP CAT5E:100m;Multi-mode Fiber:500m; Single-mode Fiber:10km
	Video Signal	MPG ／MPEG／MPV／MPA／ AVI／SWF／RM／RA／RMJ／ASF
	Support VGA Mode	800 x 600, 1024 x 768, 1280 x 1024, 1600 x 1200,
	Brightness Correction	Dot by Dot,module by module, cabinet by cabinet
	Operating Temp.	- 10° —+55° Celcius degree
	Operating Humidity	10 - 90 % RH
	Operating Life	100,000 Hours
	Protection Level	IP34
	MTBF	5000 Hours
	Out of Control Pixel Rate	0.01%

Pictures

1R1G1B Stage LED Screen SMD2121 High Brightness For Concerts/Events/Competitions

Our Projects

1R1G1B Stage LED Screen SMD2121 High Brightness For Concerts/Events/Competitions

FAQ

Q1. Can I have a sample order for led light?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than

Q3. Do you have any MOQ limit for led light order?

A: Low MOQ, 1pc for sample checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for led light?

A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.

Q6. Is it OK to print my logo on led light product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
